HELIOREF30K

Home >> HELIOREF30K

INDIGENOUS TECHNOLOGY.  ADVANCED PERFORMANCE.

HELIOREF30K

At the core of every high-performance cryocooler refrigeration system lies the helium compressor – the powerhouse responsible for delivering the high-purity compressed helium gas that drives the closed-cycle process.

The HELIOREF30K system is designed with precision engineering to unlock the full potential of GM cryocooler. The helium compressor HelioPulse3k and refrigerator REF30K are designed to operate in sync with seamless precision and reliability.

Indigenously Developed Technology

High Cooling Performance

Compact & Lightweight Design

Easy Maintenance

Enquire Now
Download Brochure
Compressor specifications:

Model:

HelioPulse3k

Technology:

Scroll

Power#:

2.4 kW, 50Hz

Electrical rating:

415V,3Ph, 50Hz

Cooling water requirement:

@ 7 LPM @ 11 ℃

Weight:

125 kg

Dimensions:

Approx. 0.6x 0.6 x 0.6 m

Flexible pipes:

2 Nos. fitted with Helium leakproof Aeroquip couplings

Helium Pressure (at start):

HP 245 ± 10 psig
LP 50 ± 5 psig

Operating temp:

Operating temp:

Noise:

65 dBA at 1 meter

Refrigerator specifications:

Model:

REF30K

Certified cooling capacity at 50Hz:

3 W at 30 K & 27 W at 77 K

Lowest temperature *:

≤ 27 K (without load)

Cooldown time:

≤ 30 minutes

# With our cryocooler at an operating temperature of 30 K.
*Lowest temperature and cooldown time are for reference only.
Specifications subject to change without notice.

Salient Features:

  • Engineered and manufactured by Indian innovations.
  • Engineered and manufactured by Indian innovations.
  • Spare parts are locally available.
  • Its lightweight and compact design allows the cryocooler refrigerator to work at any angle even for the most demanding applications.
  • Speed of motor can be ramp up to 90 RPM, this feature allows you to dynamically prioritize between peak cooling performance and optimized performance.
  • Most of the maintenance can be performed in the field. However, the mean time between service intervals is 10,000 hours.

Accessories for Cryogenic Applications

Stainless steel braided corrugated hose pipes

Stainless steel braided corrugated hose pipes

  • Suitable for Helium handling
  • Tested with Helium at 25 bar or as per requirement along with test certificate
  • For required length from 1m to any length
  • Available with / without coupling
Parker make Aeroquip Self sealing couplings of 5400 series

Parker make Aeroquip Self sealing couplings of 5400 series

  • Self sealing
  • Zero leakage
  • Suitable for Helium Gas
Vacuum Jacketed Transfer Hose for Liquid Nitrogen

Vacuum Jacketed Transfer Hose for Liquid Nitrogen

  • Outer surface is safe to touch
  • Reduced cryogen losses
  • 1/4" - 2" inner hose
  • 150 psi standard design with higher pressures available
  • Test Certificates for Jacket and Pipe shall be provided
